Gas Cylinder Valve Oxygen Pressure Ignition Resistance Test System
Gas Cylinder Valve Oxygen Pressure Ignition Resistance Test System is developed in accordance with the requirements of "GB 15382 General Technical Requirements for Gas Cylinder Valve" and other standards. It is used to test the oxygen pressure ignition resistance of various gas cylinder valves whose medium is oxygen or strong oxidizing gas. Fire test to check whether the cylinder valve is safe when ignited by oxygen pressure.
Technical Parameters:
Test medium: oxygen;
Oxygen concentration: ≥99.5%;
Rated working pressure: 36MPa;
Medium temperature: 60°C+3°C;
Compressed air pressure: 0.5~0.8MPa;
Booster pump air consumption: 1.6Nm3/min;
Pressure test accuracy: ± 0.5% FS;
Pressure control accuracy: ±2%FS;
Test station: 1;
Control mode: automatic control.
Features:
The booster system cabinet is equipped with buttons, mechanical instruments, manual pressure relief valves, emergency stops, etc. for emergency and backup operations;
The system has a high-precision automatic control system, closed-loop feedback, and intelligent PID adjustment system. The pressure sensor is located at the terminal of the test workpiece to ensure test pressure control accuracy;
The control principle is advanced and can accurately control the pressure. The pernod effect is good, and the music can be supplemented and reduced according to the test needs. The test process can be controlled softly through the computer, or each valve can be manually controlled through the button switch on the control cabinet to complete the manual test;
The supercharger and all high-pressure valves, pipe fittings and joints are imported or well-known domestic brands, with reliable quality, guaranteed pressure level, improved stability and reliability, and further improved control accuracy;
The control system has alarm shutdown protection measures for overpressure, leakage and other unexpected conditions;
Essenton's special testing software is stable, has a simple interface, and is user-friendly to operate. Product information can be entered freely. Test parameters can be set as required and automatically saved. After all information is entered, the test can be automatically completed with one click;
The software in the test process can display the pressure-time curve and temperature curve in real time, display real-time data, and can be connected to a printer to print test reports. It is compatible with OFFICE office software, and the test report can be arranged according to customer design;
It has a power-off protection function. After a power outage, the system automatically relieves pressure and stops the test to maximize the safety of operators and equipment;
Test products, methods, and reports are easy to query or retrieve, and the software output report format is word or excel.
