Valve Actuator Output Torque Test System

Valve Actuator Output Torque Test System

Valve Actuator Output Torque Test System is applied for testing the output torque of the angular stroke rotary valve actuator. The actuator angular stroke output torque test range is 10KN.M, and the measuring stroke is -5°~95°.

Technical Parameters:

Action form: dynamic testing;

Test torque range: 1000N.m -10000N.m;

Torque sensor range: 12000N.m:

Speed: 3 rpm, -5°~95° about 5 seconds ;

Hydraulic oil: 46# anti-wear hydraulic oil ;

Test station: 1 work station, suitable for connecting 4 sets of actuators.

Actuator control (single and double acting): The control air circuit part of the 9bar actuator: input pressure adjustment, pressure monitoring, and reversal ;

Test sensor accuracy: 0.5%FS:

Control mode: manual connection, automatic test .
