Safety Valve Online Calibrator
Safety valve online calibrator equipment is applied for online testing of safety valves. The safety valve does not need to be removed from the equipment during testing. Online testing instruments are used to detect the opening pressure of the safety valve. When the safety valve is tested online, the system does not need to stop and production will not be affected. ,Convenient.
Technical Parameters:
Test workpiece: safety valve;
Diameter: DN15~DN600 bomb safety valve ;
Ambient temperature: normal temperature;
Connection method: mechanical series connection ;
Measurement method: cold online, hot online
External force lifting method: manual hydraulic power unit;
Maximum lifting force: 50 kN :
Measuring pressure range: 0~60MPa;
Valve stem lifting height range: 0~8mm:
Pressure measurement accuracy: 0.5 level sensor and 1.6 level pressure gauge;
Estimated dimensions of the equipment: 600mm long x 400mm wide x 300mm high. (for reference only)
