Pipe Air Tightness Test System

Pipe Air Tightness Test System is applied for air sealing performance testing and leakage testing of various metal pipes, rubber pipes and pressure pipe components.

Technical Parameters:

Pressure range: 0~210MPa; (can be higher)

Test medium: nitrogen/nitrogen/air, etc. (please consult for special media)

Medium temperature: normal temperature; (please consult for special temperature requirements)

Test station: 1; (can be expanded)

Clamping method: threaded connection or flange connection;

Pressure measurement accuracy: ±0.5%FS; (Higher accuracy optional)

Pressure control accuracy: ±2% FS;

Driving air: 0.5MPasP<0.8MPa;

Control mode: automatic/manual;

Timing range: 0~999h;

Power supply voltage: AC 380V 50Hz.
