Tubular Heat Exchanger

Tube heat exchanger is a heat exchanger widely used in chemical industry and alcohol production. It is mainly composed of shell, tube plate, heat exchange tube, head, baffle, etc. Ordinary carbon steel, copper, or stainless steel can be used as manufacturing materials. When using it to exchange heat, one fluid enters from the connecting tube of the head, flows in the tube, and flows out from the outlet pipe at the other end of the head. This process is called the tube pass; the other fluid enters from the connecting tube of the shell. , flows out from another pipe on the shell, this process is called the shell side.

Inquire Now

It is a heat exchanger widely used in chemical industry and alcohol production. It is mainly composed of shell, tube plate, heat exchange tube, head, baffle, etc. Ordinary carbon steel, copper, or stainless steel can be used as manufacturing materials. When using it to exchange heat, one fluid enters from the connecting tube of the head, flows in the tube, and flows out from the outlet pipe at the other end of the head. This process is called the tube pass; the other fluid enters from the connecting tube of the shell. , flows out from another pipe on the shell, this process is called the shell side.

Technical Parameters

Heat exchange area 1㎡~1000㎡

Pipe side pressure 0.1~10.0MPa

Pipe material S30408/S31603, etc.

Shell side pressure 0.1~10.0MPa

Shell side material S30408/S31603, etc.

Structural form: tube rack/fixed tube plate type/floating head type
