Compression Fitting Vacuum Tester
The joint vacuum test bench is suitable for testing the sealing performance of various joints, pipes, valves, filters, low-pressure containers and other products under vacuum conditions; the whole set of equipment is automatically controlled by computer and PLC, and all tests can be completed on the console. At the same time, the equipment is also equipped with a manual drain valve to drain the water sucked into the equipment.
Main technical parameters:
1.Medium temperature: normal temperature;
2.Ambient temperature: normal temperature;
3.Control mode: automatic control, manual control;
4.Test station: 1 independent station;
5.Working pressure: 0 kPa ~-50 kPa :
6.Pressure control accuracy: +2%:
7.Pressure measurement accuracy: -100 kPa ~10 kPa ;
8.Working conditions: Suitable for clean indoor conditions;
9.Buzzer alarm function: voltage drop alarm device is set in the software;
10.The software interface can output an independent pressure-time curve.
