Not finding the pressure, temperature, or volume you are looking for? Please feel free to contact us, Let us customize a system for you.

Essenton’s Custom Reactor Systems can be efficiently and cost effectively designed and built to meet your unique requirements. Our experienced technical sales, engineering, and production teams work directly with you to quickly, accurately, and economically proceed from system concept though manufacturing.

Inquire Now

Technical Parameters

Model	EST-5	EST-10
Size,mL	5	10
Stand Type
No. of Reaction Vessels	3
Max Pressure	3000 psi (207 bar, 200 bar for CE/UKCA orders)
Maximum Temperature (internal)
with EP O-ring	150°C
with FKM O-ring	225°C
with FFKM O-ring	275°C
with Carbon-Filled PTFE Flat Gasket	300°C
Closure
with O-ring	Screw Cap
with Flat Gasket	Screw Cap (6 Compression Bolts)
Material of Construction	T316SS
Controller	E1200
Analog Inputs	4 Temperature (3 vessels, 1 heater block) 3 Pressure 1 Motor Speed
Analog Outputs	1 Stirrer Speed
Digital Outputs	1 PID Temperature Control
Temperature Measurement	Individual Thermowell in Each Vessel
Heater	Aluminum Block
Heater Power Watts	500W
Block Mounted	Thermocouple Included
Stirrer Motor	Manual or Computer Controlled
Stirrer	PTFE-or Pyrex-encapsulated Magnetic Stirrer Bars
Electrical Supply	Single phase Volts, AC 115 / 230, 50Hz/60Hz
Maximum Load	amps 4.6/ 2.3
Vessel Dimensions
Inside Diameter, mm/inches	15.7/0.62	20/0.80
Inside Depth, mm/inches	27/1.06	31/1.22
Weight of Vessel, KGs/pounds	1.6/3
Dimensions of Main Unit(mm)	W200H560D270
Spare Parts Kit
