Alternating Pressure Tester

Alternating Pressure Tester

The alternating pressure testing machine performs repeated pressure increase and decrease simulation loading on the pressure instrument within the working pressure range to detect whether the product meets the service life. It is suitable for pressure alternation (aging, aging) testing of pointer pressure gauges, pressure sensors, differential pressure sensor products, spring tubes, and pressure sensitive components. It is designed and manufactured in accordance with relevant national and industry standards. It is widely used in production inspection and development research of various pressure instruments in pressure instrument production factories, product quality inspection institutes, scientific research institutions and other units.

Reference implementation standards:

GB/T 1226-2017 General pressure gauge; GB/T 1227 Precision pressure gauge; GB/T 15478 Pressure sensor performance test method;

CN ISO19879-05 Test methods for fluid power transmission connections; other standards.

Technical Parameters:

Test pressure: 0-210MPa; (please consult for higher);

The medium temperature and the ambient temperature are both: normal temperature;

Test station: Made on demand;

Pressure control accuracy: 5%FS;

Pulse frequency: 0~1.5Hz;

Timing range: 0~10000h;

Power source: AC380V 50Hz or 0.8MPa driving air;

Medium: hydraulic oil, water or air;
