1, Agitators, stirrers
Impellers, turbine, anchor type, stirrers for any application
Depending on the stirring or mixing task, Essenton reactors can be equipped with stirrers of different types.
For gas entrainment as in hydrogenations, the Rushton type turbine stirrer is often used.
2, Bottom valves, needle valves, ball valves
Compact bottom valves, high pressure needle valves, ball valves
Bottom valves, other valves
Bottom outlet valves for pressure reactors
Bottom outlet valves
Inner diameter: DN3 - DN25
Temperature: 350 °C
Pressure: 350 / 500 bar - 5000 / 7000 psi
Material: stainless steel, Hastelloy®, Titanium etc.
Essenton bottom valves are very compact, available for different operating conditions and functions. Solenoid bottom valves with a pneumatic actuator are used for automated opening / closing with signal feedback of the status.
Needle valves, ball valves
Needle valves and ball valves for low and high pressures are installed on the reactor head as needed. Solenoid needle and ball valves with pneumatic actuators are used for automated opening / closing with signal feedback of the status.
3, Catalyst baskets
Catalyst testing and screening in pressure reactors
Catalyst testing, catalyst screening
Catalyst testing covers several types of research such as catalyst effectiveness, yield, activation, lifetime and regeneration.
The type of catalyst baskets varies depending on the catalyst being used, the interaction with the chemistry, the temperature, the pressure and the number of catalysts in the basket. Exposure to the reactants can be done through a stationary catalyst bed or a spinning basket.
Our special accessories offer solutions for more complex problems in pressure reactions in the field of catalyst research.
Catalst Basket with gasing stirrer
Robinson Mahoney Catalyst Basket
Static Catalyst Baskets
Spinning Catalyst Basket
Spinning Catalyst Basket for Pellets
4, Sampling systems
Sampling under pressure
Sampling systems for manual and automated sampling
Systems for manual and automated sampling (up to 4 samples per run) during pressure reactions, see also Parallel Pressure Reactor system PPR.
Sampling system for pressure reactors,
Sampling with the reactor under pressure,
with immersion tube and filter, sampling cylinder,
Connection for flushing the lines and sampling cylinder
Sampling System for Pressure Reactor
Automated Sampling
5, Burettes, feeding funnel
Feeding of liquids, solid, gas
Burettes
Volume: 10 - 1000 ml
Pressure: depending on material
Material: Glass, stainless steel, Hastelloy®
Burettes are available in glass with protective jacket or as full metal version for higher pressures with sightglass. Feeding funnels enable fast charge of solids and liquids.
Burettes, Gas/Liquid Additon under Pressure
6, Probes & sensors for process control
Temperature, pressure, stirrer rpm, torque, pH
Probes for process control
Probes for process control
Probes are available to measure the different process parameters. These values can be displayed on our monitoring instrument and recorded in our bls software.
Frequently measured parameters are:
temperature
pressure
stirrer speed
torque
pH
IR probes, probes to control particle sizes etc. from other suppliers can be integrated into our pressure reactors or stirred autoclaves.
7, Reflux distillation, condenser, heat exchanger
Reflux condenser, heat exchanger, distillation setups
Condensers / heat exchangers
Complete setups for reflux distillation under vacuum and pressure
If very fast heating or cooling is required, an internal heat exchanger can be installed.
For distillation under pressure and under vacuum, complete setups in glass or metal can be attached to the reactor head, including column, reflux condenser, receiver.
Reflux condensers heat exchangers for pressure reactors
Internal heat exchanger for fast heating / cooling
Vacuum distillation, Reflux condenser, Receiver
Reflux distillation under pressure
8, Safety devices
Rupture disc saftey device for pressure reactors
Safety devices for pressure reactors
Chemical reactions under pressure request high safety standards. Rupture discs and pressure relief valves are often connected to a blow down tank for safety reasons.
9, Pressure filter
Filtration under pressure, filters for lab - and pilot plant reactors
Pressure filters for laboratory and pilot plant
Robust and compact pressure filters
Pressure vessel: 5 to 20 liter
Pressure: -1 (FV) to 60 bar
Temperature: -10 °C to +200 °C
Material: Stainless steel, Hastelloy®, other materials upon request
Pressure filters with optional heating jacket for temperature controlled filtration. These robust and compact pressure filters are designed for filtration, pressurizing the vessel with up to 6 bar pressure.
They offer a removable filter basket, a quick opening / closing system and a perfect fit for Essentonpressure reactors, allowing easy operation.
The pressure filters are available in various sizes and filter types as well as with an optional heating jacket for temperature-controlled filtration.
Lab pressure filter, pilot filter
5 - 20 liter pressure filter for research laboratory
Easy access to filter for discharge
Filter for lab pressure reactor
Standard Options
Electric heating / water cooling
Reactor lift / lowering
Etc.
