Nominal volume (L): 50~5000
Operating pressure: -0.1~10.0Mpa
Operating temperature: room temperature ~300℃
Heating methods: jacketed steam, jacketed thermal oil electric heating tube, far infrared, jacketed oil circulation, etc.
Stirring speed (r/min): 20~1000r/min adjustable
Mixing blade type: propeller type, paddle type, anchor type, turbine type
Kettle cover openings: stirring port (equipped with magnetic stirrer), gas phase port (equipped with ball valve, used for intake, exhaust, and vacuum), liquid phase port (can be equipped with ball valve and bottom tube inserted in the kettle, for process sampling or discharging) Use), feeding port (with blind plate), temperature measurement and control port (with protective tube and platinum resistor), pressure gauge safety explosion port (with pressure gauge and safety explosion-proof device), inlet and outlet of the cooling coil in the kettle (with valve) . Optional: Discharging port at the bottom of the kettle (equipped with valve), gas sampling port (equipped with valve and sampler system), liquid sampling port (equipped with valve and sampler system), inlet and outlet (equipped with one-way valve), gas inlet ( Equipped with pressure reducing valve), gas outlet (equipped with back pressure valve), kettle body and lid (equipped with observation glass window, kettle body liquid level gauge).
The control system function module is expandable: it can be equipped with a PID temperature control meter with self-tuning function, temperature control accuracy of ±0.5℃, with internal speed display and stepless speed regulation function, with adjustable heating voltage function, and equipped with heating voltmeter, Motor ammeter, working time display table. Continuous operation control system: gas boosting system, liquid feeding system, isobaric feeding tank, receiving and condensing device, high-pressure separation device, mass flow control system, automatic cooling system, pressure sensor overpressure alarm, overtemperature alarm power outage, computer Remote control, data collection, etc.
Kettle body material: 1Cr18Ni9Ti (321), 00Cr17Ni14MO 2 (316L), 0Cr18Ni9 (304), nickel, nickel-based alloy (Hastelloy, Monel, Inconel), titanium, copper, zirconium, tantalum, aluminum and Its alloys, duplex stainless steel, polytetrafluoroethylene, etc.
The working environment of the controller: ambient temperature is 0~50 ℃, relative humidity is 30~85%, and the surrounding medium does not contain conductive dust or corrosive gases.
