Hydraulic Torque Wrench Calibration Device

Hydraulic Torque Wrench Calibration Device

Hydraulic Torque Wrench Calibration Device can automatically test the rated torque of the torque wrench. It can be used as factory calibration equipment for torque wrench manufacturers, and can also be used as calibration equipment for user units and quality inspection units.

Technical Parameters:

Test medium: hydraulic oil:

Test pressure: 0~70MPa (can be higher);

Test accuracy: 0.1% FS;

Control accuracy: better than 1% FS

Hydraulic output: 1 channel (expandable);

Electric pump flow: 2.12L/min (can be higher)

Power supply: 380VAC, 50Hz, power 3 kW.

Features:

Using servo control technology, the voltage control accuracy is high and the voltage boost speed is fast.

The analysis software has a Chinese version, can support QR code scanning, can support printer printing, and files can be stored as excel, PDF, etc.

The system has a blue/white or color backlit LCD screen that can display various pressure units such as PSIBAR\MPA (the host computer is a computer)

The accuracy of the pressure sensor is better than 0.1%FS, the stability is 0.1%FS/year, and the measurement range is 0~100MPa;

Parameters such as the number of detection points, the number of detection points, the number of single-point detections, and the stable value and stable range of the single-point detection pressure value can all be adjusted through the host computer .

Working Conditions:

Normal working environment conditions of the equipment:

Ambient temperature is 0~40°C

Relative humidity ≤90%, no corrosive gas,

Pressure adjustment range: 0.5~70 MPa:

Oil cleanliness requirements: better than NAS1638 level 9.
