Water Hammer Test System

Water Hammer Testing Machine

Water hammer testing machine equipment is mainly used for water hammer pressure burst testing of water purification equipment and water hammer wave impact pressure fatigue testing. It is also suitable for products that require water hammer testing, such as water purifiers, water purifiers, heaters, water pumps, pipe fittings, valves, pipelines, containers, thermoplastic pipes and composite pipes.

Inquire Now Next Product

Technical Parameters:

Water hammer wave impact pressure: 0.014~3MPa; (can be higher)

Water hammer bursting pressure: 0~8MPa; (can be higher)

Pulse frequency: 1HZ; (can be higher)

Number of cycles: 100,000 to 300,000 times; (can be higher)Pressure measurement accuracy: ±0.5%FS; (can be higher)

Temperature control accuracy: ±1℃.

Standards:

QB/T4144-2010 Reverse osmosis water purifier for household and similar purposes;

GB/T 30306-2013 Drinking water treatment core for household and similar purposes;

GB/T 30307-2013 Drinking water treatment devices for household and similar purposes;

GB/T6111-2003GB;

GB/T15560-1995;

GB/T10544-1989;

Other standards.
