The ultra-high-pressure hydraulic pump station system mainly consists of a hydraulic source device composed of a hydraulic pump, a driving motor, a fuel tank, a relief valve, etc. or a hydraulic device including a control valve. The oil is supplied according to the flow direction, pressure and flow required by the driving device. It is suitable for various machines where the driving device and the hydraulic station are separated. The hydraulic station and the driving device (cylinder or motor) are connected with oil pipes. The hydraulic system can meet various regulations. Control of oil flow direction, pressure and flow actions and other functions.
Various non-standard ultra-high-pressure hydraulic pump station systems can be customized according to needs.
Technical Parameters:
Pressure: 70-140MPa (can be higher);
Traffic: according to demand;
Medium: hydraulic oil, water glycol, mineral oil, special hydraulic working oil or other phosphate ester liquids, etc.;
Features:
Ultra-high pressure, the maximum pressure can reach 20,000psi (1380bar) or even higher;
Using imported original pump and valve accessories, the performance is more stable and reliable;
All pipeline connection systems are made of imported steel pipes and adopt thread compression cone hard seal connection technology, which is convenient for disassembly, assembly, inspection and maintenance, is safe, reliable and has stable performance.The whole machine - integrated skid-mounted or cabinet design, easy to use and save space.
