Applications:
Static pressure and burst testing of various metallic and non-metallic pipes;
Hydrostatic test and burst test of various gas cylinders and pressure vessels;
Hydraulic strength and burst tests of various shells and cylinders;
Pressure resistance and burst testing of various valves;
Pressure resistance and burst testing of various petroleum tools;
Pressure testing and blast testing of firefighting equipment such as fire hoses and fire extinguishers;
Pressure burst testing of heat exchangers, heat exchangers, hydraulic hoses, hydraulic engineering components and other products;
Other products that require burst testing.
Technical Parameters: (for reference only, please consult us if any assitant)
Pressure range: 0~1500MPa;
Applicable media: water, hydraulic oil and other media; (please consult for gas media)
Test temperature: normal temperature, -45℃~120℃;
Control mode: automatic/manual.
Features:
Using a pump imported from the United States as the pressure source, the test pressure is high, the maximum pressure can reach 690MPa, the output pressure can be adjusted steplessly, and the pressure increase rate can be set freely;
Using multiple pumps for pressure supply, the output flow is larger and the test range is wider, which can meet the blast pressure test requirements from 1 to 690MPa;
All pumps, valves and pipelines are made of 316 stainless steel, imported from the United States, and can be applied to most liquid pressure testing media such as water, oil, and emulsion;
The testing machine can adopt a two-level control system of computer and microcontroller. The entire test process can be completed on the computer. The computer automatically generates pressure and time curves, stores various data, and can print out test reports at any time. The test process can also be controlled manually through button switches; (optional)
During the test process, pressure compensation can be automatically performed, with the characteristics of stable test pressure and high pressure test accuracy;
Computerized automatic pressure relief and manual pressure relief dual pressure relief devices, as well as overpressure, timeout, and leakage alarm systems, make the entire equipment safer and more reliable; (optional)
The pressure test site uses cameras for real-time monitoring, allowing for unmanned pressure test sites; (optional)Essenton testing software is mature and stable, and the humanized operation interface facilitates user operation and monitoring. (optional )
