Application:
Hydraulic flaw detection;
Pressure resistance and burst testing of small valves;
Pressure vessel hydrostatic test and burst test;
Static pressure and burst testing of various metallic and non-metallic pipes;
Pressure resistance test of various petroleum tools;
Pressure testing and calibration of pressure instruments;
Pressure testing and blast testing of firefighting equipment such as fire hoses and fire extinguishers;Inject chemical reagents into the high-pressure reactor;
Testing of automobile braking systems;
Hydraulic systems, hydraulic components, sealing performance, static pressure and burst testing of hydraulic components.
Technical Parameters: (for reference only, please consult us if outside the range)
Pressure range: 0~1000MPa;
Test medium: water, hydraulic oil and other liquid media;
Medium temperature: normal temperature, high/low temperature -45℃~160℃;
Ambient temperature: normal temperature, high/low temperature -50℃~180℃;
Testing stations: 1~10;
Pressure measurement accuracy: ±0.5%FS;
Pressure control accuracy: ±1% FS;
Driving pressure: compressed air 0.1MPa~0.8MPa;
Control mode: automatic/manual.
Features:
Use high-quality pneumatic liquid booster pumps and electric pumps, ultra-high-pressure valves, pipe fittings, and connectors imported from the United States;
The system design is reasonable, the component quality is stable and reliable, and the system operation is guaranteed to be stable and reliable in principle and in terms of spare parts;
The entire machine piping system is made of stainless steel, with weldless connections and cone seals, which is suitable for most hydraulic system sealing requirements;
The core components are imported from the United States to ensure the quality and safety of the equipment. The material is 316 stainless steel and can be applied to most liquid pressure test media;
Data collection system. (optional)
