Technical Parameters: (for reference only, please consult us if outside the range)
Pressure range: 0~210MPa;
Test medium: air, nitrogen, nitrogen and other gas media;
Medium temperature: normal temperature; (please consult for special temperature requirements)
Testing stations: 1~multiple;
Pressure measurement accuracy: ±0.5%FS;
Pressure control accuracy: ±1% FS;
Timing range: 0~999h;
Driving pressure: compressed air 0.1MPa~0.8MPa;
Test chamber: determined according to the test workpiece and test environment medium;
Control mode: automatic/manual.
Application:
Air pressure testing and leakage testing of pressure-bearing components such as pump bodies, valves, pipe fittings, pressure vessels, and shells;
Air tightness testing of various petroleum tools;
Various pneumatic component sealing performance tests;
Air bag filling, hot isostatic press, nitrogen filling of aircraft tires and hydraulic accumulators, instrument calibration and other various air sealing performance tests similar to the gas cylinder filling principle;Suitable for static pressure testing and leakage testing of other products, such as radiators, condenser tubes, compressor shells, heat exchangers, etc.
Features:
Using pneumatic pumps or electric pumps imported from the United States as the pressure source, the test pressure can reach up to 210MPa, the output pressure can be adjusted steplessly, and the pressure increase rate can be set freely;
During the test, pressure compensation can be automatically performed;
The air pressure test bench adopts a two-level control system of computer and microcontroller, which has the characteristics of stable test pressure and high pressure test accuracy;
Computer automatic control and button switch manual control are optional. It can automatically generate pressure and time curves and store various test data, making it easy to print test reports at any time;
Computerized automatic pressure relief and manual pressure relief dual pressure relief devices, coupled with overpressure, timeout, and leakage alarm systems, make the entire equipment safer and more reliable;
The pressure test site uses cameras for real-time monitoring, allowing for unmanned pressure test sites; (optional)
Essenton testing software is mature and stable, and the humanized operation interface facilitates user operation and monitoring;
Pumps, valves, pipe fittings, and joints are all imported from the United States to ensure the quality and safety of the equipment. The material is 316 stainless steel and can be used for most gas pressure test media;
Data collection system. (optional)
