Technical Parameters:
Test medium: compressed air;
Ambient temperature: room temperature;
Test pressure: 0~0.1 steplessly adjustable; (-0.1~0.1, 0~0.5, 0~0.7.0~5 ranges are also available)
Leak detection range: 0~0.1MPa ; (Higher pressure optional)
Test station: 1; (can be added)Pressurization method: computer automatically adjusts pressure and detects automatically;
Pressure measurement accuracy: high-precision micro-pressure sensor, 0~0.05MPa , 0.1 level accuracy, minimum display 50 Pa , and higher accuracy, 25 Pa optional.
Features:
The whole machine adopts an integrated design and has a compact structure;
High-precision micro-pressure sensor with high detection accuracy;
Using LabView professional measurement and control software as the development platform, it adopts a two-level control mode of upper computer and lower computer. The control software is mature, the interface is user-friendly, the operation reliability is high, and the software can be upgraded and updated;
Test data is automatically collected and processed, and a test database is automatically established, which can be queried at any time and stored permanently;
It can display test curves and parameters in real time, and store and record test results. The stored data can be exported in Office document format;
The control system is computer-based control, which increases the flexibility of the system. It is a solution that integrates control, human-machine interface, data processing, communication and other functions into one PC, which reduces the amount of information processed by the PLC and CPU and improves processing Performance, improve the overall running speed, expand the overall storage capacity and data processing capacity;
In the event of an emergency shutdown, the internal pressure of the sample and equipment can be manually released.
