Technical Parameters:
Inlet pressure range: max15MPa (high pressure type) or max1MPa (low pressure type);
Test pressure range: 1-100Kpa, (refer to the selection range) software setting program control;
Output flow: max1000nL/min;Interface: 1/4" NPTF*4 (inlet, outlet, standard port, exhaust);
Pressure control: ≤0.5%FS;Pressure measurement: <0.1%FS;
Temperature measurement: -50-150℃±0.5℃;
Leak detection: pressure drop method or differential pressure method.
Function:
Equipped with a high-pressure pressure reducing valve, which can be directly connected to the gas cylinder;
Equipped with a mechanical safety valve to ensure safe use;
Large flow pressure reducing valve for fast filling;PID closed-loop control proportional regulating valve automatically controls pressure output with high accuracy;
One machine can be used for dual purposes, and can use either the pressure drop method or the differential pressure method to detect leaks;
Zero-leakage valve ensures automatic pressure stability of the system;Equipped with a fast filling valve, the workpiece can be filled quickly;
Equipped with 5u high-precision filter to ensure the cleanliness of the gas and the working life of the valve;
The pressure pipeline uses all stainless steel seamless pipes with no welding connections, which ensures stable operation and easy maintenance;
The electrical control part follows the electrical industry standards and uses well-known brand electrical components, with stable control performance and true and reliable data;Use touch screen operation, 7-inch screen, can display pressure and time curves in real time, humanized operation interface, can set pressure, pressure holding time, pressure drop and other data to achieve automated testing;
Optional computer software:
a) Achieve long-term storage of data, and connect a printer to print test reports;
b) Test products, test reports, test methods and other data are all stored and managed in a special database to facilitate query and retrieval;
c) Monthly reports, quarterly reports, and annual reports can be automatically generated according to customer requirements;
d) Test reports can be uploaded to the factory LAN, enabling sharing of test data.
