Toilet Gravity Flushing Device Life Testing Machine
The life test machine of gravity flushing device for toilet is mainly used for the durability test of water inlet valve, drain valve and flushing tank.
The equipment meets or exceeds GB/T 26730 Gravity flushing device and sanitary ware rack for sanitary ware toilet , EN997 Toilet with integral water trap , ASSE1002/ASMEA112.1002/CSAB125.12-15 Performance requirements for anti-siphon water inlet valve for toilet, DINEN14124 Water inlet valve for water tank with internal overflow device, ASMEA112.19.5/CSAB45.15-17 Flush valve and positioning pin for flush toilet, ASMEA112.19.10 Modification of double-speed flushing device for toilet, IAPMO50 Double-speed drain valve for toilet or toilet tank with integrated double-speed flushing device, AS1172.2 Toilet with water consumption of 6/3L or equivalent water volume Part 2: Water tank, BSEN14055 Flushing tanks for toilets and urinals, China Building Sanitary Ceramics Association standard "Gravity flushing devices for sanitary ware toilets"
Main technical parameters:
1.Maximum pressure of water system: static pressure 1.0 MPa, dynamic pressure 0.5 MPa, accuracy level 1.0;
Pressure sensor: range 0~1.6MPa, accuracy 0.25 level, stability ±0.02MPa; acquisition frequency 900Hz to ensure the accuracy of water pressure;
2.Temperature control range and accuracy: ≤30℃, accuracy +1℃;
Temperature sensor: range -50℃~120℃, accuracy +0.5℃, minimum display 0.01℃;
3.Force control range and accuracy: 25N~30N, accuracy ±1N;
Force sensor: range 0~100N, accuracy level 1.0: force application speed is adjustable, up to 50mm/s±5mm/s.
3、The double flush drain valve can be freely set according to the full flush and half flush ratio, and the time interval between two drainages can be freely set.
Main functions of the equipment:
The gravity-type flushing water device life test can test the water inlet valve, drain valve and flushing water tank, automatically test according to the test requirements, automatically record the pressure, test times, operating force, temperature and other test data, and have abnormal alarm and other functions;
The test results can be exported as standard reports;
With water tank water temperature control function;
Automatic pressure adjustment;
Install the conversion joint tooling and connect the pipe sections according to the standard configuration ;
The equipment has functions such as automatic liquid level detection, automatic water addition, water recycling, abnormal pressure alarm, etc.
