Pipeline Transportation Characteristics Test Device

Pipeline Transportation Characteristics Test Device



The pipeline transmission characteristic test device is used for the toilet pipeline transmission characteristic test. It meets or exceeds the requirements of GB/T6952 sanitary ceramics, ASME A112.19.2/CSAB45.1:2018 ceramic sanitary ware, and JC/T 2116 non-ceramic sanitary ware.



Technical Parameters:

Pipeline length: Organic glass tube (inner diameter φ 100mm ± 1mm), length 36 meters (2 sets, one set of lower discharge type and one set of rear discharge type).

Inclination: Downstream slope 0.020+0.002:

Water supply pressure: 0~0.4, accuracy 0.5 level, pressure adjustable

Pressure monitoring device: 0~1.0MPa, accuracy level 0.5.



Features:

Toilet pipe transport characteristics test, with water supply, pipe with scale, can observe the transport distance.
