Intelligent Toilet Seat Cover Life Tester
The intelligent toilet seat cover life tester is suitable for the swing, opening and closing, strong pressure, slow drop and static pressure tests of the intelligent toilet integrated machine and the intelligent cover. It meets or exceeds the requirements of standards such as "IC/T 764 Toilet Seat and Cover", "JG/T 285 Toilet Bidet", and "CBMF15 Intelligent Toilet".
Technical parameters:
1.Swing cylinder pressure range and accuracy: 0~1800N Accuracy 1.0 level:
Force sensor: range 0~2500N, repeatability 0.1 level, ensuring the accuracy of pressure force value;
Can generate 1335N alternating swing pressure load:
2.Static pressure cylinder pressure range and accuracy: 0.0~3000N, accuracy level 1.0;
Force sensor: range 0~3000N, repeatability 0.1 level, ensuring the accuracy of pressure force value ;
Can generate static pressure load greater than 1500N.
3.The angle between the seat ring and the cover and the horizontal plane is >95° after opening:
Open and close slow drop strong pressure angle 0~110 degrees, precision level 1
It can realize strong pressure from 70°, and the opening and closing time is 0.5~1.0 seconds
4.The rest meet the requirements of relevant items in JC/T 764-2008 "Toilet Seat and Cover", JG/T285-2010 Toilet Bidet, and CBMF15-2016 Intelligent Toilet Standard.
Equipment functions:
Swing of the smart toilet integrated machine and the smart cover; opening and closing, strong pressure, slow drop, static pressure test;
Special fixture, automatic testing, automatic recording of test data (force, angle, time, etc.).
