Technical Parameters: (For reference only, please free contact us for custom needs)
Pressurization range: 0~690MPa;
Pressure accuracy: ≤±1%;
Constant pressure accuracy : -1%~+2%;
Experimental pipeline: 1;
Left Indent
Medium: water or hydraulic oil.
Standards:
SAE.J 157
GB 16897
GB/T 5563
GB/T 10544
GB-T 15560.,etc.
Features:
All test processes are automatically controlled by PLC, and the test time, test pressure and other values are displayed in real time:
The test time can be set freely, and the machine will automatically stop after the test is completed;
The pressure test site is monitored in real time by cameras, which can realize unmanned pressure test site; ( optional )
Pumps, valves, pipe fittings and joints are all imported from the United States to ensure equipment quality and safety. The material is SUS 316Stainless steel, suitable for most liquid pressure test media;
With overpressure, timeout and leakage monitoring functions, it will automatically alarm and terminate the test.
